Ultra-Quiet 3200i

Generator Type

Inverter

Maximum AC Output (Watts)

3200

AC Voltage Available

120

Maximum Continuous AC Output (Watts)

2600

Max. Rated AC Amperage @ 120 V / 240 V

21.7 -

Ground Fault Circuit Interrupter (GFCI)

N/A

Frequency (Hertz)

60

Automatic Voltage Regulator

Standard

DC Output Volts / Amps

DC not equipped

Common Duplex Receptacle Specifications

21.7 amps/120 VAC continuous is available as combined total from these two AC receptacles. Maximum of 20 amps is available from a single receptacle.

DC Receptacle Specifications

DC not equipped

DC Charging Cable

N/A

High Capacity 120 / 240 VAC Twist Lock Receptacle Specifications

This receptacle (NEMA # L5-30R) will supply 23.3 amps at 120 VAC continuously.

Engine Type

Honda GX130 OHV, 4-stroke, air-cooled

Displacement

130 cc

Starting System

Recoil / Full transistor

Low Level Oil Alert System

Standard

Auto Throttle

Eco-Throttle standard

Remote Start Capability

No

Fuel Tank Capacity

4.6 litres (1.01 Imp. gal.)

Transport Wheels

N/A

Lifting Hook

N/A

Battery

N/A

Approximate Running Time (hrs.) / Tankful

3.3** / 8.6***

Rated Fuel Consumption (litres/hr)

1.43**

Noise Level dB(A)

TBD

Length (Without Handles and Wheels)

571 mm (22.5 in.)

Length (With Handles and Wheels)

N/A

Width (Without Handles and Wheels)

306 mm (12.0 in.)

Width (With Handles and Wheels)

N/A

Height (Without Lift-Hook)

452 mm (17.8 in.)

Height (With Lift-Hook)

N/A

Dry Weight

27 kg (59 lbs.)

Cold Climate Technology

Standard

** / ***

**At max. rated output (continuous) in Watts.
***At 25% rated output (continuous) in Watts.
